Expandable Braided Sleeves for Wire Harness Management

3

Expandable Braided Sleeves for Wire Harness Management

The Expandable Braided Sleeve is a premium protective solution designed for efficient cable and wire harness management. Manufactured with high-quality polyester monofilaments, this sleeve offers excellent abrasion resistance, flame-retardant performance, and flexibility, ensuring long-lasting protection in demanding industrial environments. Its unique braided construction allows the sleeving to expand easily during installation, with a fully expanded diameter reaching at least 1.5 times its initial size. This makes it particularly suitable for covering wire harnesses, especially when passing through large or irregular connectors, providing convenience and ease of operation. Specification sheet Part No. Nominal size - W Expandable range Packing -L Inch mm Min.I (mm) Max.O (mm) standard spool GSKJ-PET-003 1/8″ 3 1 6 100M/R GSKJ-PET-005 1/4″ 6 3 9 100M/R GSKJ-PET-008 5/16″ 8 5 16 100M/R GSKJ-PET-010 3/8″ 10 7 19 100M/R GSKJ-PET-012 1/2″ 12 8 24 100M/R GSKJ-PET-016…
