940nm IR Band Pass Filter for ToF

15

940nm IR Band Pass Filter for ToF

940nm IR Band Pass Filter for ToF   This 940 nm bandpass filter is specifically designed to align with the atmospheric 0.94 µm H₂O absorption band, which effectively minimizes solar background interference and enhances the signal-to-noise ratio (SNR) of outdoor 3D sensing applications when used in conjunction with 940 nm vertical-cavity surface-emitting lasers (VCSELs) in time-of-flight (ToF) depth cameras. Major industry vendors specifically design 940 nm VCSEL arrays for ToF and LiDAR systems to ensure reliable performance across a wide range of ambient lighting conditions. Camera manufacturers commonly provide 850/940 nm wavelength options, with the 940 nm variant being preferred for superior daylight performance. Silicon-based sensors maintain high responsivity up to approximately 1100 nm, typically peaking near 960 nm, thereby ensuring robust system performance at 940 nm. Similar to all thin-film interference filters, an increase in the angle of incidence (AOI) causes a blue shif…
